Signal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone system

  • 1
  • 2
  • 3

Brand Name : Texin

Model Number : TX-PD 50W

Certification : ISO CE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, T/T, ,Paypal,etc

Supply Ability : 10000pcs per month

Delivery Time : 1-3 days

Packaging Details : Durable case or box

Brand : Texin

Type : Jamming module

power : 50W

frequency : 5.8ghz

Features : 5.8ghz 50W circulator

Connector : SMA / Female

Application : Office,Hotel , Car ,etc

Advantage : Gan circulator

Voltage : 28V

Current : 4.8A

Weight : 1050G

Contact Now

Signal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone system

It is a wirelessRF drone signal shield security module dedicated to 5725~5850MHz signals. This module has the advantages of high average output power (50W output in stable operation), good in-band flatness, and small offset between upper and lower sidebands.

We are a professional signal jammer module manufacturer , support frequency band customization based on the customers' requirements

Parameters

No.ItemDataUnit
1Frequency5800MHz
2Test voltage28V
3Current4.2A
4Output50W
5Gain47dB
6Output stability1dB
7ConnectorN / male
8Output connector VSWR≤1.30 (No power and VNA test)
9Power supply wireRed+Black+Enable wire
10Enable ControlHigh ON Low Off
11Out shell Size150*53*20mmmm
12Mount hole48*126mm
13Weight316g
14Work Temperature-40~+65℃
15Out shell materialAluminum
16Vibration needCar load OK

Features:


*Working frequency band: 5.7~5.9GHz
*Working voltage: 32V
*Maximum output power (P1dB): 50W (47dBm)
*Working current: 4500mA@Pout 47dBm 28V
*Average efficiency: 40%
*Working temperature: -20℃～60℃


Physical Structure

  • Shell size: 53*130*19mm
  • RF interface: the output end is SMA external thread and internal needle
  • Power supply port: red and black wire
  • Shell: aluminum material, natural color oxide sandblasting
  • Fixed holes: four fixed positions around the shell
  • Net weight: 0.254KG

Pictures:

Signal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone system

Signal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone systemSignal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone system

Signal Blocking28V 50W SMA female circulator 5.8ghz transmit module for anti drone system
